When installing the ventilation duct, the air duct hanger is also a very important link in the installation of the ventilation duct. The air duct hanger can make the ventilation duct more stable, and the installation of the air duct hanger is convenient and has many advantages. Next, with the steps of Jinan ventilation duct manufacturer, let's have a detailed understanding of the installation knowledge of the air duct hanger together, hoping to help the screen You.

濟南通風管道

Jinan ventilation duct

濟南通風管道廠家?guī)盹L管吊架的安裝知識：

Installation knowledge of air duct hanger brought by Jinan ventilation pipe manufacturer:

風管吊架安裝是通風管道施工中一個很重要的環(huán)節(jié)，對管道起著支承重量、平衡介質反力、限制位移和防止震動等作用。通風管道制作安裝公司為大家介紹下吊架安裝的知識：

The installation of air duct hanger is a very important link in the construction of ventilation pipeline, which plays the role of supporting weight, balancing medium reaction force, limiting displacement and preventing vibration. Ventilation pipe production and installation company introduces the following hanger installation knowledge:

1、按風管的線找出吊桿敷設位置，單吊桿在風管的線上，雙吊桿可以按托盤的螺孔間距或風管的線對稱安裝。

1. According to the center line of the air duct, find out the laying position of the suspender. The single suspender is on the center line of the air duct, and the double suspender can be installed symmetrically according to the screw hole spacing of the tray or the center line of the air duct.

2、吊桿根據吊件形式，可以焊在吊件上，也可掛在吊件上，焊接后應涂防銹漆。

2. The suspender can be welded on the hanger or hung on the hanger according to the form of the hanger, and anti rust paint shall be applied after welding.

3、當風管較長時，需要安裝一排支架時，可先把兩端安好，然后以兩端的支架為基準，用拉線法找出中間支架的標高進行安裝。

3. When the air duct is long and a row of supports need to be installed, the two ends can be installed first, and then the elevation of the middle support can be found out by using the guy wire method based on the supports at both ends.

4、立管管卡安裝時，應先把更上面的一個管件固定好，再用線錘在處吊線，下面的管卡即可按線進行固定。

4. During the installation of riser pipe clamp, the top pipe fitting shall be fixed first, and then the line hammer shall be used to hang the line at the center, and the pipe clamp below can be fixed according to the line.

在管道設，合理布置和正確選擇結構合適的支吊架，能改善管道的應力分布，確保管道安全運行并延長管道的使用壽命。所以吊架的安裝過程要多加重視，

In the pipeline design, reasonable layout and correct selection of supports and hangers with appropriate structure can improve the stress distribution of the pipeline, ensure the safe operation of the pipeline and prolong the service life of the pipeline. Therefore, more attention should be paid to the installation process of the hanger,

濟南通風管道

Jinan ventilation duct

以上就是濟南通風管道廠家給大家分享的關于風管吊架的安裝知識了，不知道對屏幕前的您有沒有幫助呢?

The above is Jinan ventilation duct manufacturers to share with you about the installation of duct hanger knowledge, do not know to the screen you have help?
